8
Specifi cations
KohlerEngines.com 14 690 10 Rev. --
TORQUE SPECIFICATIONS
2,5
HD675 HD775
Muffl er
Exhaust Stud 5.0 N·m (44 in. lb.)
Lock Nut 9.5 N·m (84 in. lb.)
Shoulder Screw 9.5 N·m (84 in. lb.)
Oil Pan (torque sequence on page 6 )
Oil Drain Plug
6
13.6 N·m (120 in. lb.)
Fastener 11.0 N·m (98 in. lb.) 14.7 N·m (130 in. lb.)
Retractable Starter
Fastener 8 N·m (71 in. lb.)
Rocker Arm
Stud 13.6 N·m (120 in. lb.)
Pivot Jam Nut 9.5 N·m (84 in. lb.)
Speed Control
Bracket Assembly Fastener 8 N·m (71 in. lb.)
Valve Cover (torque sequence on page 6 )
Fastener 8 N·m (71 in. lb.)
CLEARANCE SPECIFICATIONS
2
HD675 HD775
Camshaft
End Play 0.3/0.85 mm (0.0118/0.0335 in.)
Running Clearance 0.013/0.0555 mm (0.00051/0.00217 in.)
Connecting Rod
Connecting Rod-to-Crankpin Running Clearance
New 0.025/0.045 mm (0.0009/0.0017 in.)
Connecting Rod-to-Crankpin Side Clearance
New 0.03/0.48 mm
(0.00118/0.0189 in.)
0.13/0.58 mm
(0.0051/0.0228 in.)
Connecting Rod-to-Piston Pin Running Clearance 0.008/0.025 mm (0.0003/0.0009 in.)
Piston Pin End I.D. New @ 21°C (70°F) 13.006/13.017 mm
(0.5120/0.5125 in.)
18.006/18.017 mm
(0.7088/0.7093 in.)
Crankcase
Governor Cross Shaft Bore I.D.
New 6.000/6.024 mm (0.2362/0.2372 in.)
2
Values are in Metric units. Values in parentheses are English equivalents.
5
Lubricate threads with engine oil prior to assembly.
6
Apply thread sealant around three full threads before assembly. No excess sealant allowed on inside or outside of
joint. Threads with preapplied sealant do not require use of additional sealant. Approved sealants include Perma-Loc
LH 150, Perma-Loc MM 115, Perma-Loc HH 120, Perma-Loc HL 126.
