Kohler HD Series Service Manual

7
Specifi cations
14 690 10 Rev. -- KohlerEngines.com
TORQUE SPECIFICATIONS
2,5
HD675 HD775
Brake (if equipped)
Mounting Fastener 9.5 N·m (84 in. lb.)
Breather Cover
Fastener 10 N·m (89 in. lb.)
Carburetor
Stud Fastener 8 N·m (71 in. lb.)
Stud 5 N·m (44 in. lb.)
Auto Choke Arm Assembly Nut (if equipped) 8.5 N·m (75 in. lb.)
Auto Choke Arm Assembly Screw (if equipped) 2.3 N·m (20 in. lb.)
Connecting Rod
Cap Fastener (torque in increments) 12.5 N·m (110 in. lb.)
Cylinder Head (torque sequence on page 5 )
Fastener (torque in 2 increments) fi rst to 14 N·m (123 in. lb.)
fi nally to 27.8 N·m (246 in. lb.)
Dipstick Tube (if equipped)
Fastener 8 N·m (71 in. lb.)
Electric Starter (if equipped)
Fastener 9.5 N·m (84 in. lb.)
Finger Guard (as equipped)
Fastener (Muffl er Side, Carburetor Side) 9.5 N·m (84 in. lb.)
Flywheel
Retaining Nut 51.5 N·m (38 ft. lb.)
Fuel Pump (if equipped)
Pump to Bracket Fastener 2.3 N·m (20 in. lb.)
Stud (into crankcase) 10 N·m (89 in. lb.)
Lock Nut (Bracket to Studs) 8 N·m (71 in. lb.)
Fuel Tank
Stud 10 N·m (71 in. lb.)
Lower Tank Bracket to Crankcase Screw 8 N·m (71 in. lb.)
Governor
Lever Fastener 9.5 N·m (84 in. lb.)
Gear Fastener 9.5 N·m (84 in. lb.)
Ignition
Spark Plug 27 N·m (20 ft. lb.)
Module Fastener (Stud or Screw) 10 N·m (89 in. lb.)
Stator Screw (if equipped) 9.5 N·m (84 in. lb.)
2
Values are in Metric units. Values in parentheses are English equivalents.
5
Lubricate threads with engine oil prior to assembly.
