Operation – Controls and Shower Arms
Adjust the Water Flow and Temperature
CAUTION: Risk of product damage. Do not force the handle in any direction. The shower valve
shuts off by water pressure.
Rotate the shower valve handle clockwise to turn on the water and set the water temperature.
To turn the valve off, gently turn the handle counterclockwise to the OFF position.
Select Spray Options
Rotate the transfer valve handle to select one of the six available shower settings.
Adjust the Telescopic Shower Arms
Adjust the height of the shower arms by gripping the shower arms and sliding them up or down.
The shower arms can also swing from side-to-side.
Rotate the easy-grip rings on the showerhead to change the spray pattern.
Counterclockwise
Close
Shower Valve
Transfer Valve
OFF Position
Clockwise Open
Telescopic Shower Arms
Easy-Grip Rings
1000706-5-D 6 Kohler Co.
