Kohler K-682 Installation Guide

6. Massage Cycling Configurations (DTV and DTV II)
NOTE: Primary outlets and any outlets designated as handshowers will not be included in the cycling
pattern. For installations that include both bodysprays and watertiles, the outlets designated as watertiles
will not cycle.
For massage cycling configurations for DTV+, refer to the guide found on the K-99695 controller
product page at www.us.kohler.com.
Single
Custom
Surround
Downpour
Linear
Dual
DualSingle Wave
WaveSingle
Wave
WaveDualSingle
= Constant on
= On while cycling
Configuration 4
Configuration 5
Configuration 6
Kohler Co. 11 1043183-2-E
