4. Custom Shower Configurations (DTV and DTV II)
Draw in the fittings for your custom shower.
Draw lines from the valve to each fitting. Be aware that:
•
Outlet 1 should be the primary showerhead.
•
The installer must determine the desired sequence for Single mode and plumb the ports to the
bodysprays accordingly.
•
Custom mode will allow the user to select a different water outlet as the primary showerhead, but it
is not recommended.
•
In Custom mode, the bodysprays will cycle up the solenoid bank regardless of which port is the
primary outlet.
Ceiling
Wall 1
Wall 2
Wall 3
Floor
Wall 1
Wall 2
Floor
CH
12 34 56
CH 12 34 56
Kohler Co. 9 1043183-2-E
