12 Introduction TP-7070 7/18
Nameplate Location
Generator sets and their components (engine,
alternator) are identified with decals or nameplates. For
future reference during routine maintenance or to order
service parts, copy the model number, serial number,
and specification number from the generator set
nameplate into the spaces provided in the product
information section on the inside front cover of this
manual.
The generator set nameplate is typically located on the
alternator assembly as shown in Figure 3.
Service Duty
Voltage
Alt Model
Insulation
MFG Date
Amps
Phase
RPM
Battery
Fuel
kW
kVA
Hz
Genset Model
Spec Number
Serial Number
Material Number
PF
Figure 2 Generator Set Nameplate, Typical
1
11811000100--GR1
1. Nameplate location, typical
Figure 3 Generator Set Nameplate Location, Typical
