Kohler KD2000 User Manual

TP-7070 7/1852 Section 2 Operation
2.12 Menus
Figure 2-57 shows the architecture of the screens accessible from the Menu button.
Menu >
1--Settings 2--Measurements 3--History 4--Diagnostic 5--Configuration 6--Hardware
1.2 2.2 3.1 4.1 5.1 6.1
Power thresholds Mechanical Archiving Va riables Application Installation
1.5 2.3 4.2 5.1.1 6.1.1
Timers * Generator electrical Binary inputs General General
1.6 2.6 4.3 5.1.2 6.1.2
Auxiliaries Harmonics Binary outputs Alarms Generator set
1.8 4.4 5.1.3 6.1.3
Parameters Regulation/Protection Status messages Regulator
4.5 5.1.4 6.1.4
* Not used. Regulation Function key Engine sensor
5.1.5 6.1.5
Custom view--
Visualization
Auxiliaries
5.1.6 6.2
Custom view --
Parameters
Base inputs/outputs
5.1.7 6.2.1
Main screen custom
view
Configurable binary
inputs
5.1.8 6.2.2
Time slots Resistive inputs
5.1.9 6.2.3
Advanced setpoints Analog inputs
5.1.10 6.2.4
Customer messages Analog outputs
5.2 6.3
Generator Extension
inputs/outputs
5.2.1 6.3.1
Starting CAN#1 inputs/outputs
5.2.2 6.4
Speed Regulation/Protection
5.2.3 6.4.1
Excitation General
5.2.4 6.4.2
Miscellaneous Regulation modules
5.2.5 6.5
Timers Communication
5.3 6.5.1
Regulation Ethernet
5.3.1 6.5.2
Regulation parameters Serial link
5.3.2
Speed regulation PID
5.3.3
Voltage regulation PID
5.3.4
Synchronization PID
Figure 2-57 Screen Architecture
