Kohler KDI Series

174
11
_07
Fig. 11.25
Fig. 11.26
A
C
N
B
C D
E
G H L
M
A1
F
B
Fig. 11.24
A2
ED0053029590
INFORMATION ABOUT OPTIONAL COMPONENTS
11.6.1 Disassembly
1 - Undo the screws A and remove the pump B.
2 -
Remove the centring ring C and the relative gaskets.
3 - Undo the screws N.
11.6 3
rd
PTO (replacement)
