180
11
_07
A3 A4
B K H D C
C
D
H
K
Fig. 11.45
Fig. 11.46
ED0053029590
INFORMATION ABOUT OPTIONAL COMPONENTS
11.8 3
rd
+ 4
th
PTO (configurations)
11.8.1 Information
Hydraulic pumps on the 3
rd
and 4
th
PTO can be installed at
the same time.
In some congurations, there is also the centering ring C on
the 4
th
PTO.
Important
• For disassembly or installation, refer to Par. 11.5,
Par. 11.6 and Par. 11.7.
• Always replace the gasket of the rings B and C and flanges
D and K at each assembly.
• Lubricate the gear H with oil.
