SPECIFICATIONS
TP-6901 3/16a Specifications 45
Section 8 Specifications
8.1 ENGINE SPECIFICATIONS
Item Specifications
Engine Model KG2204 KG2204T
Block Type I-4
Number of Cylinders 4
Cylinder Bore 91 mm (3.5 in.)
Piston Stroke 86 mm (3.4 in.)
Displacement 2.2 L (134.25 in.
3
)
Rated Output 30 kW (40 HP) @ 1800 rpm 47.8 kW (64.1 HP) @ 1800 rpm
Fuel Type Propane, Liquid Petroleum Gas (LPG) or Natural Gas (NG). See
“Fuel Specifications” in Section 4.
Oil Type / Weight KOHLER synthetic engine oil, SAE Class SJ or higher. Variable
per ambient temperature.
See “Oil Recommendations” in Section 5.
Oil Dry Fill Capacity 4.2 L (4.4 qt.)
Rotating Direction of Crankshaft Counterclockwise (face to flywheel)
Compression Ratio 10.5:1
Cylinder Fire Order 1-3-4-2
Lubricating Style Pressurized
Starting Style Electric
Net Weight (Dry) 145 kg (320 lb.)
Overall Dimensions (L x W x H) 826 x 547 x 647 mm (32.5 x 21.5 x 25.5 in.)
Aspiration Natural Turbocharged
Charge Air Cooler NA Aluminum core
