6. Specifications
400V
MODEL
PW3000/P1 10K
PW3000/P1 20K
CAPACITY*
10KVA / 10KW
20KVA / 20KW
INPUT
Voltage
Range
Low Line Loss
110 VAC(Ph-N) ± 3 % at 50% Load
176 VAC(Ph-N) ± 3 % at 100% Load
Low Line Comeback
Low Line Loss Voltage + 10V
High Line Loss
300 VAC(L-N) ± 3 % at 50% Load
276 VAC(L-N) ± 3 % at 100% Load
High Line Comeback
High Line Loss Voltage - 10V
Frequency Range
46Hz ~ 54 Hz @ 50Hz system
56Hz ~ 64 Hz @ 60Hz system
Phase
3 Phase with Neutral OR Single Phase with Neutral (Single or Dual)
Power Factor
≧ 0.99 at 100% Load
OUTPUT
Phase
Single phase with Neutral
Output voltage
220/230/240VAC (Ph-N)
AC Voltage Regulation
± 1%
Frequency Range
(Synchronized Range)
46Hz - 54 Hz @ 50Hz system
56Hz - 64 Hz @ 60Hz system
Frequency Range (Batt. Mode)
50 Hz ± 0.1 Hz or 60Hz ± 0.1 Hz
Overload
AC mode
100% -110%: 60min; 110% -125%: 10min; 125% -150%:1min;>150% :
immediately
Battery mode
100%~110%: 60min; 110%~125%: 10min; 125%~150%:1min;>150% :
immediately
Current Crest Ratio
3:1 max
Harmonic Distortion
≦ 2 % @ 100% Linear Load; ≦ 5 % @ 100% Non-linear Load
Transfer
Time
Line Battery
0 ms
Inverter Bypass
0 ms (When phase lock fails, <4ms interruption occurs from inverter to bypass)
Inverter ECO
<10 ms
EFFICIENCY
AC mode
96.6%
Battery Mode
95.5%
Eco Mode
99.0%
BATTERY
Numbers
(10+10)pcs
Up to 2 strings Internal – 40pcs
Max (20+20) pcs
Up to 1 String Internal – 40pcs
Recharge Time
9 hours recover to 90% capacity
Charging Current (max)
2.0 A ± 10% (Recommended)
1.0~12.0A (Adjustable)
Charging Voltage
+/-136.5 VDC ± 1%
+/-218 VDC ± 1%
Type
Depending on applications
Numbers
20
32 ~ 40 (adjustable)
Charging Voltage
+/- 13.65 VDC * N ± 1%
(N = 10)
+/- 13.65 VDC * N ± 1% (N = 16~20)
PHYSICAL
Standard
Model
Dimension, D x W x H (mm)
710 x 250 x 827
Net Weight (kgs)
141
141
ENVIRONMENT
Operation Temperature
0 - 40°C ( A temperature of 20°C is recommended to achieve a long battery life)
Operation Humidity
<95 % and non-condensing
Operation Altitude**
<1000m**
Acoustic Noise Level
Less than 55dB @ 1 Metre
Less than 58dB @ 1 Metre
MANAGEMENT
Smart RS-232 or USB
Supports Windows® 2000/2003/XP/Vista/2008/7/8/10, Linux, Unix, and MAC
Optional SNMP
Power management from SNMP manager and web browser
* Derate capacity to 90% when the output voltage is adjusted to 208VAC.
**If the UPS is installed or used in a place where the altitude is above than 1000m, the output power must be de-rated 1% per 100m.
***Product specifications are subject to change without further notice.
