I.3 Nameplate
The nameplate depicted below is attached to the side of the servo amplifer.
The information described below is printed in the individual fields.
I.4 Instrument description
I.4.1 Package supplied
When you order a SERVOSTAR™ 600 series amplifier from us, you will receive:
— SERVOSTAR™ 6xx
— mating connectors X3, X4, X0A, X0B, X7, X8
The mating SubD connectors and motor connector X9 are not part of the package!
— Assembly, Installation and Commissioning Instructions
— Online documentation on CD-ROM
— Operator software SR600 on 3.5" diskettes
Accessories:
(must be ordered separately if required)
— Servomotor 6SM
— motor cable (pre-assembled), or
both motor connectors separately, with motor cable as a cut-off length
— feedback cable (pre-assembled, see manual Servomotors) or
both feedback connectors separately, with feedback cable as length
— motor chokes (for cable length above 25m)
— external regen resistor
— communications cable to the PC(ð III.7) or Y-adapter (ð IV.2.1) for parameter-
setting of up to 4 servo amplifiers from one PC
— power cable, control cables, fieldbus cables (as lengths)
- A.4.028.6/10
10 SERVOSTAR™ 600 Installation-manual
General
02.99 - A.4.028.6/10
Kollmorgen
CONNECT-module
and options
Serial numberServo amplifier type
Electrical supply
Installed load
Output current
in S1 operation
Protection
