Kollmorgen BDS4 Series

B
DS4 C
HAPTER
2 - I
NSTALLATION
2-7
Table 2.2. BDS4 Unregulated DC Voltages (C3)
VOLTAGE CURRENT
BDS4
CONNECTOR C3
PINS
PSR4/5
CONNECTOR C2
PINS
+18 V Nominal
(+17 V to +26.5 V)
NO LOAD 1, 5 1, 5
-18 V Nominal
(-17 V to -26.5 V)
NO LOAD 2, 6 2, 6
COMMON --- 3, 7 3, 7
10 V Nominal
(+9 V to +14 V)
NO LOAD 4, 8 4, 8
+ 14.5 V MIN. 1 AMP ON PSR4/5
12 OR 20 AMP
UNITS
2 AMP ON PSR4/5
50 OR 75 AMP
UNITS
1, 5 1, 5
- 14.5 V MIN. 1 AMP ON PSR4/5
12 OR 20 AMP
UNITS
2 AMP ON PSR4/5
50 OR 75 AMP
UNITS
2, 6 2, 6
COMMON --- 3, 7 3, 7
+ 6.5 V MIN. 2 AMP ON PSR4/5
12 OR 20 AMP
UNITS
4 AMP ON PSR4/5
50 OR 75 AMP
UNITS
4, 8 4, 8
+18 VDC 5 1 +18 VDC
-18 VDC 6 2 -18 VDC
COMMON 7 3 COMMON
+10 VDC 8 4 +10VDC
Figure 2.3. BDS4 (C3) & PSR4/5 (C2)
(Nominal, No Load Voltages)
FAULT
CONTACT
41
FAULT CONTACT
115 V OUTPUT
52
115 V INPUT
115 V OUTPUT
63
115 V INPUT
Figure 2.2. PSR4/5 (C1)
