DS4 A
PPENDIX
B - M
ODEL
N
UMBER
B-3
Table B.3. BDS4 Model Number Scheme
EXAMPLE: BDS
4A- 2 03 H XX* YY* \ 204A Z
LEGEND: A B C D E F G H I
LEGEND DEFINITION
A Brushless Drive Sinewave Servo Amplifier.
B
V
A
Amplifier generation indicator.
Original Standard Configuration (no letter designation).
Industrial Standard Configuration.
U.L. 508 listed configuration.
C Maximum Output Voltage.
1 115VAC (Nominal).
2 230VAC (Nominal).
D 03, 06, 10, 20, 30, 40, 55 Output RMS Current Per Phase, Continuous.
E R/D Converter.
H Standard. Accuracy 22 Arc Min. Maximum.
J Special. Accuracy 8 Arc Min. Maximum. Required for 01, 02, 03 Electrical Options or
Motors with N
max
> 3 KRPM.
F Mechanical Options.
00 Standard Unit. No Options.
01 Side Cover Option.
02 Custom.
03 Custom.
70 Custom.
71 Custom.
73 Custom.
80 Custom.
91 Side Cover Option w/ Cover, No Conn. Kit
G Electrical Options.
00 Standard Unit. No Options.
01 Electronic Encoder Output. Requires Type J R/D Converter.
02 Electronic Encoder with Parallel Output. Requires Type J R/D Converter.
03 Electronic Encoder with Parallel Output and Drive Signals Requires Type J R/D
Converter.
05 Custom.
06 Custom.
07 Same as 01 Except Configured for LSB on Channel B. (Refer to Section E.2.2.1.)
08 14-Bit R/D with 3500 RPM Tracking Rate. Requires Type J R/D
09 Comp Card Without Components.
10 Custom.
11 Custom.
12 Custom.
13 Custom.
14 Same as 01 Plus 08.
15 Direction Limit Option Board.
16 14-Bit R/D with 2000 RPM Tracking Rate. Requires Type J R/D Converter.
