PPENDIX
B - M
ODEL
N
UMBERS
BDS
B-4
LEGEND DEFINITION
17 14-Bit R/D with 3500 RPM "J" Grade, W Direction Limit Option.
18 Custom.
19 16 Bit R/D 600 RPM "J" Grade R/D.
81 Custom.
83 Custom.
84 Custom.
85 Custom.
91 Custom.
92 Custom.
93 Custom.
94 Custom.
95 Custom.
96 12-Bit R/D 14k RPM "J" Grade with encoder equivalent option.
H Motor and Winding Designator.
I Compensation Designator.
20 - 5 X Jm.
3 5 - 20 X Jm.
ZZ Special.
*XXYY Omit when there are no options.
Table B.4. Compensation Card Model Designator
EXAMPLE: CMP-
BDS4-203H 204A2
LEGEND: A B C
LEGEND DEFINITION
A Compensation Card.
B Amplifier Base Model Number.
C Motor, Winding, and Compensation Designator.
B.1 CABLE, BUS WIRE, AND MATING CONNECTOR KIT INFORMATION
Extra or spare bus wire and complete cable assemblies are available from Industrial Drives.
Mating connector kits are available from Industrial Drives or may be purchased directly from the connector vendor.
Table B.3. BDS4 Model Number Scheme (Continued)
