DS4 A
PPENDIX
B - M
ODEL
N
UMBER
B-5
B.2 CABLE MODEL NUMBER SCHEME FOR INDIVIDUAL CABLE SET
Motor cables are designed to provide reliable and cost-effective interconnection between Industrial Drives' Goldline
Series Motors and any BDS Series Amplifier. GCS (Goldline Cable Set) models provide both motor (stator) and
resolver (feedback) cable of equal length. Cables include motor mating plugs with various termination options at the
amplifier end. There are 2 versions of the cable sets; the GCS and the GCSA. The GCS is used with motors that
have MS Bayonet-type connectors, while the GCSA is used with motors that have MS screw-type connectors. To
assist in ordering, the model number scheme for a cable set is as follows:
Table B.5. Cable Model Number Scheme for Individual Cable Set
(Bayonet-Type Thread)
EXAMPLE: GCS -
M6A / R - 4/5 - 03
LEGEND: A B C D E
LEGEND DEFINITION
A Goldline Cable Set. Consists of one motor stator and one feedback cable with
Bayonet type thread.
B Motor Power Cable with mating plug for particular frame size.
M6A B-60X-X-AX & BX Motors (up to 40 amps continuous).
M6B B-60X-X-AX & BX Motors (up to 65 amps continuous).
M8A B-80X-X-AX & BX Motors (up to 65 amps continuous).
M8B B-80X-X-AX & BX Motors (up to 115 amps continuous).
C Motor Feedback/Option Cable with Mating Plug.
R System Resolver Only.
RBT System Resolver, Brake, Tachometer.
D Amplifier Termination.
4/5 BDS4 or BDS5, 3-20 Amp Models.
4/5H BDS4 or BDS5, 30-55 Amp Models.
N Not Terminated.
E Cable Length to Motor. 3 to 75 Meters in 3-Meter Increments.
