Kollmorgen BDS4 Series

A
PPENDIX
B - M
ODEL
N
UMBERS
BDS
4
B-6
Table B.6. Cable Model Number Scheme for Individual Cable Set
(Screw-Type Thread)
EXAMPLE: GCSA -
M4 / R - 4/5 - 03
LEGEND: A B C D E
LEGEND DEFINITION
A Goldline Cable Set. Consists of one motor stator and one feedback cable with screw-
type thread.
B Motor Power Cable with mating plug for particular frame size.
M4B B-40X-X-AX & BX Motors (up to 40 amps continuous).
M6A B-60X-X-AX & BX Motors (up to 40 amps continuous).
M6B B-60X-X-AX & BX Motors (up to 65 amps continuous).
M8A B-80X-X-AX & BX Motors (up to 65 amps continuous).
M8B B-80X-X-AX & BX Motors (up to 115 amps continuous).
C Motor Feedback/Option Cable with Mating Plug.
R System Resolver Only.
RBT System Resolver, Brake, Tachometer.
D Amplifier Termination.
4/5 BDS4 or BDS5, 3-20 Amp Models.
4/5H BDS4 or BDS5, 30-55 Amp Models.
N Not Terminated.
E Cable Length to Motor. 3 to 75 Meters in 3-Meter Increments.
