B.3. CABLE MODEL NUMBER SCHEME FOR INDIVIDUAL CABLE
Individual cables can be provided by GC (Goldline Cable) Models. To assist in ordering, the model number scheme
for an individual cable is as follows:
Table B.7. Cable Model Number Scheme for Individual Cable
(Bayonet-Type Connector)
EXAMPLE: GC -
M2 - 4/5 - 03
LEGEND: A B C D
LEGEND DEFINITION
A Goldline Cable With Bayonet-Type Connector (individual cable).
B Motor Power Cable with Mating Plug or Feedback/Option Cable.
M1 B-10X Motors.
M2 B-20X Motors.
M4 B-40X Motors.
M6A B-60X-X-AX & BX Motors (up to 40 amps continuous).
M6B B-60X-X-AX & BX Motors (up to 65 amps continuous).
M8A B-80X-X-AX & BX Motors (up to 65 amps continuous).
M8B B-80X-X-AX & BX Motors (up to 115 amps continuous).
R System Resolver Only.
RBT System Resolver, Brake, Tachometer.
AR Application Resolver.
C Amplifier Termination.
4/5 BDS4 or BDS5, 3-20A Models.
4/5H BDS4 or BDS5, High Current Models.
N Not Terminated.
D Cable Length to Motor. 3 to 75 Meters in 3-Meter Increments.
