Table B.8. Cable Model Number Scheme for Individual Cable
(Screw-Type Connector)
EXAMPLE: GCA -
M4 - 4/5 - 03
LEGEND: A B C D
LEGEND DEFINITION
A Goldline Cable with screw-type connector (individual cable).
B Motor Power Cable with Mating Plug or Feedback/Option Cable.
M4 B-40X Motors (up to 40 amps continuous).
M6A B-60X Motors (up to 40 amps continuous).
M6B B-60X Motors (up to 65 amps continuous).
M8A B-80X Motors (up to 65 amps continuous).
M8B B-80X Motors (up to 115 amps continuous).
R System Resolver Only.
RBT System Resolver, Brake, Tachometer.
AR Application Resolver.
C Amplifier Termination.
4/5 BDS4 or BDS5, 3 to 20 A Models.
4/5H BDS4 or BDS5, High Current Models.
N Not Terminated.
D Cable Length to Motor. 3 to 75 Meters in 3-Meter Increments.
