DS4 A
PPENDIX
B - M
ODEL
N
UMBER
B-9
B.4 SPECIAL CABLES FOR RESOLVER FEEDBACK AND INTERFACE
The GC specials are designed to eliminate the need for the customer to make crimp connections for BDS4
input/output connector (C1) and BDS4 resolver connector (C2). These cables are terminated at C1 and C2 on the
BDS4 and are unterminated at the opposite end. The unterminated end is intended to be connected into a customer-
supplied terminal block. To assist in ordering, the model number schemes for these special cables are as follows:
Table B.9. Resolver Feedback Cables
GC-RF-4/5-XX Resolver feedback flying lead cable (not terminated at the motor). XX-length in
3 meter increments; 03, 09, etc.
GC-IOF-4-XX I/O flying lead cable (not terminated at customer's interface). XX-length in 3
meter increments; 03, 09, etc.
B.5 SPECIAL CABLES FOR LOGIC POWER SUPPLY
Special logic power supply cables are available to accommodate the various physical sizes of BDS4 and PSR4/5
modules and are designed based on standard module spacing requirements. Refer to drawing B-84929 for
information concerning decoding the model numbers of special logic bus cables. To assist in ordering, the model
number scheme for this cable is:
GC-LOGIC-XXXXXXX
