DS4 A
PPENDIX
C - C
ONNECTOR
K
ITS
& T
OOL
C-1
A
PPENDIX
C
C
ONNECTOR
K
ITS
& T
OOLS
C.1 INTRODUCTION
Mating connectors are customer furnished items which may be ordered either from Industrial Drives or purchased
directly from the connector vendor. Ordering information is as follows:
Table C.1. Connector Kit BDS4C-100
INDUSTRIAL DRIVES CONNECTOR KIT -- PART NUMBER----BDS4C-100
BDS4 - 3, 6 and 10 AMP MODELS
CONNECTOR DESCRIPTION MOLEX PART NO. I.D. PART NO.
C1 Connector Housing, 20
Position Female
39-01-2205 A-83908-020
C2 Connector Housing, 12
Position Female
39-01-2125 A-83908-012
C3 Connector Housing,
8 Position Female
39-01-2085 A-83908-008
C1, C2, C3 PIN, Female,
(18-24 AWG)
39-00-0039 A-83909-002
