Kollmorgen BDS4 Series

A
PPENDIX
C - C
ONNECTOR
K
ITS
& T
OOLS
BDS
4
C-2
Table C.2. Connector Kit BDS4C-101
INDUSTRIAL DRIVES CONNECTOR KIT -- PART NUMBER----BDS4C-101
BDS4 - 20 AMP MODELS
CONNECTOR DESCRIPTION MOLEX PART NO. I.D. PART NO.
C1 Connector Housing,
20 Position Female
39-01-2205 A-83908-020
C2 Connector Housing,
12 Position Female
39-01-2125 A-83908-012
C3 Connector Housing,
8 Position Female
39-01-2085 A-83908-008
C4 Connector Housing,
4 Position Male
39-01-2045 A-83908-004
C1, C2, C3, C4 PIN, Female,
(18-24 AWG)
39-00-0039 A-83909-002
Table C.3. Connector Kit BDS4C-200
INDUSTRIAL DRIVES CONNECTOR KIT -- PART NUMBER----BDS4C-200
BDS4 - 30, 40, and 55 AMP MODELS
CONNECTOR DESCRIPTION MOLEX PART NO. I.D. PART NO.
C1 Connector Housing,
20 Position Female
39-01-2205 A-83908-020
C2 Connector Housing,
12 Position Female
39-01-2125 A-83908-012
C3 Connector Housing,
8 Position Female
39-01-2085 A-83908-008
C4 Connector Housing,
4 Position Male
39-01-2045 A-83908-004
C1, C2, C3, C4 PIN, Female,
(18-24 AWG)
39-00-0039 A-93105-002
