DS4 A
PPENDIX
C - C
ONNECTOR
K
ITS
& T
OOL
C-3
Table C.4. Connector Kit PSR4/5C-200
INDUSTRIAL DRIVES CONNECTOR KIT -- PART NUMBER----PSR4/5C-200
PSR4/5 - 12, 20, 50 and 75 AMP MODELS
CONNECTOR DESCRIPTION MOLEX PART NO. I.D. PART NO.
C1 Connector Housing,
6 Position Female
39-01-2065 A-83908-006
C2 Connector Housing,
8 Position Female
39-01-2085 A-83908-008
C1, C2 PIN, Female
(18-24 AWG)
39-00-0039 A-83909-002
Table C.5. Connector Tools
CONNECTOR TOOLS (PINS, MINI FIT JR.) FROM MOLEX
Description Engineering
Number
Order
Number
Hand Crimping Tool HTR-60622 11-01-0197
Extractor Tool HT-60630A 11-03-0038
MOLEX TELEPHONE NUMBER: (708) 969-4550
