PPENDIX
D - S
PECIFICATIONS
BDS
D-2
Table D.1. PSR4/5 Specifications
DESCRIPTION
PSR4/5-112
PSR4/5-120
Main AC Line Input Voltage 90 - 160 VAC 90 - 160 VAC
Phase 1 Phase 1 Phase
Frequency 47 - 63 HZ 47 - 63 HZ
Current RMS/Phase, Continuous 12 AMPS 20 AMPS
Current RMS/Phase, Peak (2 Sec.) 24 AMPS 40 AMPS
Current RMS/Phase, Peak (50 msec.) 50 AMPS 80 AMPS
Control AC Line Input Voltage 95 - 132 VAC 95 - 132 VAC
Phase 1 Phase 1 Phase
Frequency 47 - 63 HZ 47 - 63 HZ
Current RMS 1.5 AMPS 1.5 AMPS
Output Power 1.0 K WATTS 1.7 K WATTS
Volts 140 VDC 140 VDC
Unregulated Logic Bus Output
No Load
± 26 VDC MAX
+ 14 VDC MAX
Full Load ± 14.5 VDC MIN. @ 1 AMPS
+ 6.5 VDC MIN. @ 2 AMPS
Internal Shunt Regulator, Peak Current 30 A 30 A
Internal Shunt Regulator, Resistance 7.5 OHM 7.5 OHM
Internal Shunt Regulator, Resistor Power 40 WATTS 40 WATTS
External Shunt Regulator, Peak Current 50 A 50 A
External Shunt Regulator, Min. Resistance 5.5 OHM 5.5 OHM
External Shunt Regulator, Resistor Power Model Dependant Model Dependant
Internal Power Dissipation, Continuous
(Less Shunt Regulator)
60 W 90 W
Soft-Start Surge Current (MAX) 35 AMPS 35 AMPS
Soft-Start Charge Time (MAX) 0.25 SEC. 0.25 SEC.
