DS4 A
PPENDIX
D - S
PECIFICATION
D-3
Table D.1. PSR4/5 Specifications (Con't)
DESCRIPTION
PSR4/5-212
PSR4/5-220
Main AC Line Input Voltage 207 - 253 VAC 207 - 253 VAC
Phase 3 Phase 3 Phase
Frequency 47 - 63 HZ 47 - 63 HZ
Current RMS/Phase, Continuous 12 AMPS 20 AMPS
Current RMS/Phase, Peak (2 Sec.) 24 AMPS 40 AMPS
Current RMS/Phase, Peak (50 msec.) 48 AMPS 80 AMPS
Control AC Line Input Voltage 95 - 132 VAC 95 - 132 VAC
Phase 1 Phase 1 Phase
Frequency 47 - 63 HZ 47 - 63 HZ
Current RMS 1.5 AMPS 1.5 AMPS
Output Power 3.6 K WATTS 6.0 K WATTS
Volts 310 VDC 310 VDC
Unregulated Logic Bus Output
No Load
± 26 VDC MAX
+ 14 VDC MAX
Full Load ± 14.5 VDC MIN. @ 1 AMPS
+ 6.5 VDC MIN. @ 2 AMP
Internal Shunt Regulator, Peak Current 32 A 32 A
Internal Shunt Regulator, Resistance 12.5 OHM 12.5 OHM
Internal Shunt Regulator, Resistor Power 40 WATTS 40 WATTS
External Shunt Regulator, Peak Current * 50 A 50 A
External Shunt Regulator, Min. Resistance * 8.8 OHMS 8.8 OHMS
External Shunt Regulator, Resistor Power Model Dependant Model Dependant
Internal Power Dissipation, Continuous
(Less Shunt Regulator)
60 W 90 W
Soft-Start Surge Current (MAX) 80 AMPS 80 AMPS
Soft-Start Charge Time (MAX) 0.25 SEC. 0.25 SEC.
* The -XX03 Electrical Option version has a peak regulator current of 75 amps, a minimum resistance
of 5.8 ohms, and a power rating of 700 watts.
