Table D.1. PSR4/5 Specifications (Con't)
DESCRIPTION
PSR4/5-250
PSR4/5-275
Main AC Line Input Voltage 207 - 253 VAC 207 - 253 VAC
Phase 3 Phase 3 Phase
Frequency 47 - 63 HZ 47 - 63 HZ
Current RMS/Phase, Continuous 50 AMPS 75 AMPS
Current RMS/Phase, Peak (2 Sec.) 75 AMPS 112 AMPS
Current RMS/Phase, Peak (50 msec.) 100 AMPS 150 AMPS
Control AC Line Input Voltage 95 - 132 VAC 95 - 132 VAC
Phase 1 Phase 1 Phase
Frequency 47 - 63 HZ 47 - 63 HZ
Current RMS 3.0 AMPS 3.0 AMPS
Output Power 15 K WATTS 22.5 K WATTS
Volts 310 VDC 310 VDC
Unregulated Logic Bus Output
No Load
± 26 VDC MAX
+ 14 VDC MAX
Full Load ± 14.5 VDC MIN. @ 2 AMPS
+ 6.5 VDC MIN. @ 4 AMPS
Shunt Regulator, Peak Current 100 A 200 A
Shunt Regulator, Min. Resistance 4.3 OHM 2.15 OHM
Internal Power Dissipation, Continuous
(Less Shunt Regulator)
175 W 250 W
Internal Power Dissipation, Peak (2 SEC.) 325 W 475 W
Soft-Start Surge Current (MAX) 40 AMPS 40 AMPS
Soft-Start Charge Time (MAX) 0.5 SEC. 0.5 SEC.
