DS4 A
PPENDIX
E - O
PTION
E-1
A
PPENDIX
E
O
PTIONS
Options are brought into existence from time to time
to satisfy specific needs and to add versatility to the
product. (Refer to the Model Number Schemes in
Appendix B.)
The BDS4 and PSR4/5 may be ordered with various
mechanical and electrical options, standard or
custom designed for particular applications. If a
feature is desired which is not covered here, consult
the Industrial Drives Sales Staff for information on
custom designed options.
E.1
PSR4/5A/V ELECTRICAL
OPTIONS
12 and 20 AMP Models:
OPTION:
-01 400 watts external regeneration resistor kit
for 230V systems (refer to Section 4.7).
-02 200 watts external regeneration resistor kit
for 115V systems (refer to Section 4.7).
-03 700 watts external regeneration resistor kit
for 230V systems (refer to Section 4.7).
-80 without Regen or dynamic brake
-81 with 240 V logic supply, without Regen or
dynamic brake
50 and 75 AMP Models:
OPTION:
-20 with undervolt fault
-50 without soft-start circuitry.
E.2 BDS4 ELECTRICAL OPTIONS
The standard BDS4 servo amplifier is fitted with a
12-bit R/D converter which allows a maximum
tracking rate of 8000 RPM and a maximum operating
speed of 7500 RPM.
The BDS4 amplifiers are available with standard
options which are discussed in the following sections.
These options are either integrated into the main
circuit board of the BDS4 amplifier or appear as
Option Boards that are mounted inside of the BDS4
chassis.
E.2.1 Integrated Options
R/D Converter Resolution and Tracking Rate
Options:
Optional R/D resolutions and tracking rates are
available and produce higher resolution position
information and/or better low-speed performance.
These options are integrated into the main circuit
board (motor control board) within the BDS4
amplifier and are as follows:
Option - 08 contains a 14-bit R/D, produces a
maximum tracking rate of 3500 RPM, and a
maximum operating speed of 3200 RPM.
Option - 11 contains a 16-bit R/D, produces a
maximum tracking rate of 500 RPM, and a maximum
operating speed of 450 RPM.
Option - 16 contains a 14-bit R/D, produces a
maximum tracking rate of 2000 RPM, and a
maximum operating speed of 1800 RPM.
Accuracies, repeatability, and resolution
specifications are recorded in the tables located in
Section E.2.2.4.
