DS4 A
PPENDIX
E - O
PTION
E-5
Table E.1. BDS4-OPT2/3A-01 Board Specifications
ENCODER RESOLUTION
SELECTION MARKER PULSE WIDTH
ENCODER
RESOLUTION
OUT A & OUT B
JUMPER/HEADER
#35
DIP SWITCH #23 & #36
(0 = OFF 1 = ON)
Encoder
Quad
Encoder
Lines JUMPER JUMPER WIDE MARKER* NARROW MARKER
Counts (/rev) #1 #2
123456789 10 1112 123456789 10 1112
65536** 16384 A - B C - D
011111111 1 1 1 011111111 1 1 1
32768** 8192 C - E D - F
001111111 1 1 1 001111111 1 1 1
16384** 4096 E - F G - H
000111111 1 1 1 000111111 1 1 1
8192** 2048 G - I H - J
000011111 1 1 1 000011111 1 1 1
4096* 1024* I -J* K -L*
000001111 1 1 1* 000001111 1 1 1
2048 512 K - M L - N
000000111 1 1 1 000000111 1 1 1
1024 256 M - N O - P
000000011 1 1 1 000000011 1 1 1
512 128 O - Q P - R
000000001 1 1 1 000000001 1 1 1
256 64 Q - R S - T
000000000 1 1 1 000000000 1 1 1
128 32 S - U T - V
000000000 0 1 1 000000000 0 1 1
64 16 U - V W - X
000000000 0 1 1 000000000 0 1 1
* This is the standard setting (12-bit).
** These resolutions are not available on all BDS4 models. A high resolution R/D is also required with these
resolutions.
