Kolver FAB Series User Manual

Vers. 111219 Page 24
 CN7 CONNECTOR (9 pin serial connector - female) – PRINT FUNCTION
PIN
NAME
FUNCTION
1
+15V
Not used.
2
TX
Serial transmission.
3
RX
Serial reception.
5
GND
Common to every input. Signals have to be enabled making contact between
the desired signal and this pin (GND).
9
+5V
Not used.
 USB-PRINT CONNECTOR
Only used to print data on PC (see dedicated paragraph).
ATTENTION: Output signals are protected from an appropriate circuit. Overload of the available
signals (> 400 mA) or short circuit will result in the stop of the unit. To re-activate signals, it is
necessary to switch off the unit for 5-6 seconds, check connections and output loads then switch the
unit on.
CORRECT SCREWS MESSAGES ON DISPLAY
On the status bar it will display “Screw OK”.
A correct screwing has been performed,
reaching the pre-set torque value.
On the status bar it will display “Angle OK”.
A correct screwing has been performed,
reaching the pre-set angle.
On the status bar it will display “Runtime OK”.
A correct screwing has been performed,
reaching the pre-set runtime.
On the status bar it will display “Reverse torque OK”
A correct screwing has been performed,
reaching the pre-set reverse torque
value.
