21) Error lever: when ON, an error signal will occur when the lever has released before reaching the
torque.
When OFF, this function doesn’t work.
22) Defix allow: when OFF, the reverse is NOT enabled.
23) Calibration: When ON, you will see the torque value (Nm or in.lbs) on the main screen.
When OFF, the torque value won’t be displayed.
(To modify the calibration parameters see paragraph Torque calibration).
24) Compens – Compensation: This function allows an increase or decrease of the displayed torque
value after a calibration. The available range is from 0 to ±55 Nm. For example: after calibration (see
Torque calibration) you make a screwing on your assembly and compare the displayed value to the value
you see on a torque tester (for example a mini-K or a K model). Let's say you notice that the torque
displayed in the unit EDU 2AE/TOP is +0.2 Nm higher than the value indicated on the tester (which is the
right one). In this case you can modify this value by setting -0.2 Nm so that the value on the display will be
the same as the value on the tester. If it’s lower than 0.3 Nm, you need to set +0.3 Nm and so on.
25) Torq min – Minimum torque: The minimum torque and maximum torque options allow the user to
set the acceptable torque range for each single application. When the reached torque is within this range,
“Screw OK” will be displayed on the status bar and the green led will light up. If the reached torque is
outside this range, “error minimum torque” or “error maximum torque” will be displayed and the red led
will light up. You can set the torque range from 0 to ‘Torq Max-0.01 Nm’ in steps of 0.01 Nm.
The minimum torque option allows to set the lowest value of the torque range. When Calibration is OFF, the
minimum torque value automatically sets on 0 Nm.
The selection of the torque value is carried out by entering the digit cell by cell.
26) Torq max – Maximum Torque: The minimum torque and maximum torque options allow the user
to set the acceptable torque range for the single application. When the reached torque is within this range,
“Screw OK” will be displayed on the status bar and the green led will light up. If the reached torque is
outside this range, “error minimum torque” or “error maximum torque” will be displayed. You can set the
torque range from ‘Torq Min+0.01 Nm’ to 55 Nm at intervals of 0.01 Nm.
The maximum torque option allows to set the highest value of the torque range. When Calibration is OFF
the maximum torque value automatically sets on 55 Nm.
