SEN04120-03 40 Troubleshooting
36 PC130-8
Failure code [D19JKZ] Personal code relay abnormality 1
User code Failure code
Trouble
Personal code relay abnormality
(KOMTRAX system in machine monitor)
E01 D19JKZ
Contents of
trouble
• Disconnection or short circuit was detected in personal code relay circuit.
Action of
controller
• None in particular (when disconnection is detected).
• Turns output to personal code relay OFF (when short circuit is detected).
• If cause of failure disappears, system resets itself (when disconnection is detected).
• Even if cause of failure disappears, system does not reset itself until starting switch is turned OFF
(when disconnection is detected).
Problem that
appears on
machine
Related
information
• This failure code is displayed only when engine lock function is effective.
• Method of reproducing failure code: Turn starting switch ON (Disconnection). Trouble cannot be
reproduced on machine (Short circuit).
Possible causes
and standard
value in normal
state
Cause Standard value in normal state/Remarks on troubleshooting
1 Defective fuse No. 3 If fuse is broken, circuit probably has ground fault (See cause 4).
2
Defective personal code
relay (Internal disconnection
or short circuit)
a Prepare with starting switch OFF, then carry out troubleshoot-
ing without turning starting switch ON. (Troubleshooting for
relay unit)
R07 (male) Resistance
Between (1) – (2) (300 – 600 z)
a Prepare with starting switch OFF, then turn starting switch ON
and carry out troubleshooting. (Troubleshooting by replace-
ment)
Replace personal code relay (R07) with another relay and perform
reproducing operation. If "E" of failure code goes off at this time,
replaced relay is defective.
3
Disconnection in wiring har-
ness (Disconnection in wiring
or defective contact in con-
nector)
a Prepare with starting switch OFF, then carry out troubleshoot-
ing without turning starting switch ON.
Wiring harness between F01 (3) – R07
(female) (1)
Resis-
tance
Max. 1 z
Wiring harness between R07 (female) (2) –
CM01 (female) (6)
Resis-
tance
Max. 1 z
4
Ground fault in wiring har-
ness (Short circuit with GND
circuit)
a Prepare with starting switch OFF, then carry out troubleshoot-
ing without turning starting switch ON.
Wiring harness between F01 (3) – R07
(female) (1) and chassis ground
Resis-
tance
Min. 1 Mz
Wiring harness between R07 (female) (2) –
CM01 (female) (6) and chassis ground
Resis-
tance
Min. 1 Mz
5
Defective machine monitor
(KOMTRAX section)
If causes 1 – 4 are not detected, machine monitor (KOMTRAX)
may be defective. (Since trouble is in system, troubleshooting can-
not be carried
out.)
To Next Page
