OPERATION
TRANSPORTATION
METHOD OF LIFTING MACHINE
When lifting the machine at a port or any other place, always use the following procedure to lift it.
WARNING
The operator carrying out the lifting operation using a crane must be a properly qualified crane operator.
Never raise the machine with any worker on it.
Always make sure that the wire rope is of ample strength for the weight of this machine.
When lifting, keep the machine horizontal.
When lifting the machine, always stop the engine, apply the parking brake, and set the safety lock lever to the LOCK position.
Lock with the safety bar to prevent the front frame from articulating, and take steps to prevent the machine from moving
unexpectedly.
Never enter the area around or under the machine when it is raised.
Never try to lift the machine in any posture other than the posture given in the procedure below or using lifting
equipment other than in the procedure below.
There is a hazard that the machine may lose its balance.
NOTICE
This method of lifting applies to the standard specification machine.
The method of lifting differs according to the attachments and options installed.
For details of the procedure for machines that are not the standard specification, please consult your Komatsu distributor.
For the weight of the standard specification machine, see "WEIGHT TABLE (PAGE 3-85)".
NOTICE
Use protectors to prevent the wire rope from being cut on sharp corners and to prevent the wire rope from cutting into the
machine bodywork.
When using a spreader bar, select an ample width to prevent contact with the machine.
Please consult your Komatsu distributor before carrying out lifting work.
3 - 84
