11. EXPLANATION OF COMPONENTS
11.4 SUSPENSION SEAT, SEAT BELT AND ARM RESTS
11.4.1 SUSPENSION SEAT
Pull lever (A), and slide the seat back or forth to any one of five positions
and release the lever. Be sure the seat engages the slide rail notch.
Turn the knob (B) clockwise or counterclockwise to adjust the seat to the
operators weight.
Pull up on the back rest (C) and move the cushion to one of the three
positions.
11.4.2 SEAT BELT
Before driving the machine, adjust the seat and fasten the seat belt.
chance and severity of injury in the event of an accident. Never wear
the seat belt across the abdomen.
A
WARNING
Do not use bleach, color dye or solvents on the seat belt webbing
which may cause a severe loss of tensile strength. This could cause
the webbing to break resulting in personal injury. It is recommended
that the belt be cleaned only with warm water and a mild detergent.
To buckle, insert the tongue portion (A) of the buckle into the locking portion
(B). To release, lift the top lever plate (C) on the locking portion of the buckle
and pull the tongue plate out.
Keep belts flat to avoid twisting and roping when not being used. Do not
place heavy or sharp object on the belts.
11.4.3 ARM RESTS I
The arm rests may be adjusted up or down for the convenience of the
operator.
To raise or lower arm rests (A), loosen the front and rear mounting bolts (B)
and position to the desired height. Tighten the bolts after desired height has
been obtained.
