POSITION FOR ATTACHING SAFETY LABELS
HIGH REACH DEMOLITION MANUAL
7-14
CEILING WINDOW WIPER SWITCH
7
Roof Wiper Switch
This switch (8) is used
to turn on the r
oof wiper and to operate th
e
washer
. The switch has 3 positions:
(a) ON: Is with the rear end of the switch down. The wiper is on.
(b) ON: Is with the rear end of the switch pressed and h
eld down.
The wash/wipe is on.
(c) OFF: The wiper/washer system is of
f.
1.
Nozzle
2.
Ceiling window
3.
Ceiling wiper
c
10
c
a
b
ON
OFF
(1)
(2)
(3)
445
447
