OPERATION
2-86
13.3.3 LIFTING PROCEDURE
Lifting is only for vehicles which have decals indicating lifting positions
First stop the vehicle on level ground to ensure the vehicle will be lifted
horizontally
Then proceed with the follow instructions:
1. Start the engine, be sure the vehicle is on level ground, then set the work
equipment to the travel position. For details, see “12.7 MOVING
MACHINE OFF”on page 2-47.
2. Move the work equipment safety lock lever to the LOCK position.
3. Stop the engine, check that the area around the operator’s compartment
is safe, then LOCK the safety bar so that the front frame and rear frame
do not articulate upsetting the balance and causing the lifting to be
unstable.
4. Hook up the lifting equipment to the lifting positions (marked by the lifting
decals) at the front portion of the front frame, and the rear portion of the
rear frame.
5 After raising the vehicle 100 to 200 mm above the ground, check the posture
to be sure it is horizontal and check the wire ropes to be sure there is no
slack.
WARNING
When lifting the machine, check for any oil leaks from the hydraulic
circuit or any other part.
