MAINTENANCE
3-45
24.5.2 CLEAN ELEMENT IN AIR CONDITIONER FRESH AIR FILTER
WARNING
When using compressed air, wear safety glasses and other things
required to maintain safety.
If the air conditioner has been used, then its air filter element could need cleaning.
Before cleaning the elements, turn the air conditioner OFF.
1. Loosen the thumb screws (1) and remove cover (2).
2 Unsnap the two clips (3) holding the element, and remove element (4) to
clean it.
3 Direct compressed air (less than 7 kg/cm [100 psi / 689 kPa]) to the
2
element from the inside along its folds, then direct it from the outside
along its folds and again from the inside. Check the element for damage
and/or deterioration.
REMARKS:
When re-assembling the element, install it so that the arrow on top of the filter is facing the inside of the cab.
