2.5.2.6. Override function
Override (OVR) control of the unit can be performed by the external contact
(see Picture 1.3 b) or device (timer, switch, thermostat, etc.). The received signal
from the outside activates the OVR function, which ignores the current operation
modes of the unit and performs one of the selected actions listed below:
• switches o󰀨 the air handling unit;
• switches over the unit to operation according to the mode “Comfort1”;
• switches over the unit to operation according to the mode “Comfort2”;
• switches over the unit to operation according to the mode “Economy1”;
• switches over the unit to operation according to the mode “Economy2”;
• switches over the unit to operation according to the mode “Special”;
• switches over the unit to operation according to the weekly schedule.
Reset settings
Enable
Override
If on
Mode
ECONOMY 1
Override function
2.5.2.7. Humidity control
Humidity control function is designed for maintenance of air humidity determined
by the user. For proper operation of the function one or two additional humid-
ity sensors shall be connected, depending on where humidity will be maintained.
There are two modes for maintenance of humidity:
• Supply air. The determined humidity of supply air is maintained, using the
supply air duct humidity sensor (B9).
• Room air. The determined humidity of indoor air is maintained, using the room
air or exhaust air duct humidity sensor (B8). The supply air humidity limit is set
using the duct humidity sensor or hydrostat (B9).
One of the below methods can be chosen for maintenance of the determined
humidity:
• Humidication of air. There is a control signal of 0...10 V, directly reecting
the capacity of the humidier from 0 to 100 %. If humidication is required, the control is transferred through
the output TG3 of the controller.
• Dehumidication of air. There is a control signal of 0...10 V, directly reecting the capacity of the dehu-
midier from 0 to 100 %. If dehumidication is required, the control is transferred through the output TG3
of the controller.
• Dehumidication of air: cooling-heating. Dehumidication is performed using the coolers and heaters
available in the air handling unit. If there are several coolers and heaters, then it shall be pre-determined
which of them will be used in the dehumidication process.
• Humidication and dehumidication of air. For humidication of air the control signal of 0...10 V is used
through the output TG3 of the controller, and the dehumidication of air is performed using the coolers and
heaters available in the unit.
If the maintenance of the room air humidity is provided for, then the hu-
midity function will prevail over the air quality and recirculation functions,
i.e. when humidication or dehumidication is required, these functions
will be blocked.
Humidity control function must be ordered in advance.
Reset settings
Enable
Setpoint 1
55% RH
Mode 1
COMFORT 1
Setpoint 2
30% RH
Mode 2
ECONOMY 2
Humidity control
The OVR function provides for three operation modes selectable depending on the needs of the user:
1. The mode “When on” – the function will respond to the external control contact only when the air handling
unit is on.
2. The mode “When o󰀨” – the function will respond to the external control contact only when the air handling
unit is o󰀨.
3. The mode “Always” – the function will respond to the external control contact irrespective of the operating
condition of the unit.
The OVR function has the top priority and, therefore, ignores all previ-
ous modes. The function remains active as long as the external control
contact is in the closed position.
