DESCRIPTION
CONNECTING AND INSTALLING
Plug the Konftel 200W in the
mains using the power adapter as
illustrated. Place the conference
phone in the middle of the table.
Tape recorder socket
Sockets for
expansion
microphones
Display
Speaker LEDs Microphone
Receiver
remote control
Keypad
Power supply
Cable duct
Holes for wall bracket
