Konica Minolta bizhub 20 User Manual

Scanning
40
2
Scanning a document using the WIA driver
(Windows
®
XP/Windows Vista
®
/Windows
®
7) 2
WIA compliant 2
For Windows
®
XP/Windows Vista
®
/Windows
®
7 you can choose Windows
®
Image Acquisition (WIA) for
scanning images from the machine. You can scan images directly into the PaperPort™ 11SE viewer that
KONICA MINOLTA included with your machine or you can scan images directly into any other application
that supports WIA or TWAIN scanning.
Note
• Windows
®
XP does not support Duplex Scan in the WIA driver.
• Duplex Scan is not available for legal size paper.
Scanning a document into the PC 2
There are two ways in which you can scan a whole page. You can either use the ADF (automatic document
feeder) or the scanner glass.
If you want to scan and then crop a portion of a page after pre-scanning the document, you need to use the
scanner glass. (See Pre-Scanning to crop a portion you want to scan using the scanner glass on page 42.)
a Load your document.
b Start the ScanSoft™ PaperPort™ 11SE software that was installed during the Multi-Function Suite
installation to scan a document.
Note
The instructions for scanning in this Guide are for when you use ScanSoft™ PaperPort™ 11SE. The
scanning steps may vary when using other software applications.
c Click File, then Scan or Get Photo.... You can also click the Scan or Get Photo button.
The Scan or Get Photo panel appears on the left side of the screen.
d Click Select button.
e Choose the scanner you are using from the Available Scanners list.
Note
Choose WIA:KONICA MINOLTA bizhub 20, WIA:KONICA MINOLTA bizhub 20 LPT or
WIA:KONICA MINOLTA bizhub 20 LAN.
f Check the Display scanner dialog box on the Scan or Get Photo panel.
g Click Scan.
The Scanner Setup dialog box appears.

Konica Minolta bizhub 20 Specifications

General

Network ready	Yes
Scan file formats	JPG, PDF, TIFF, XPS
Dimensions (WxDxH)	530.8 x 452.1 x 474.9 mm
Networking features	Fast Ethernet
All-in-one functions	Copy, Fax, Print, Scan
Color all-in-one functions	Scan
Compatible operating systems	Windows 2000 Professional Windows XP Home Windows XP Professional (32/64-bit) Windows Server 2003 (32/64-bit) Windows Server 2008 (R1/R2) Windows Vista Windows 7 Mac OS X v10.3.9+
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Print speed (black, normal quality, A4/US Letter)	32 ppm
Digital sender	No
Printing colors	Black
Maximum duty cycle	30000 pages per month
Number of print cartridges	1
Page description languages	PCL 6, PostScript 3
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
Maximum number of copies	99 copies
N-in-1 copy function (N=)	2, 4
Time to first copy (black, normal)	10.5 s
Copy speed (black, normal quality, A4)	32 cpm
Scan to	E-mail, FTP, USB
Grayscale levels	256
Input color depth	24 bit
Maximum scan area	Legal (216 x 356) mm
Scan speed (black)	20 ppm
Scan speed (color)	8 ppm
Image formats supported	JPG, TIF
Maximum scan resolution	19200 x 19200 DPI
Optical scanning resolution	600 x 2400 DPI
Faxing	Mono faxing
Fax memory	600 pages
Modem speed	33.6 Kbit/s
Fax coding methods	JBIG, MH, MMR (Fax coding method), MR
Fax speed dialing (max numbers)	300
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum input capacity	550 sheets
Auto document feeder (ADF) input capacity	50 sheets
Custom media width	70 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	116 - 406 mm
Paper tray media types	Bond paper, Plain paper, Recycled paper, Transparencies
Paper tray media weight	60 - 105 g/m²
Non-ISO print media sizes	Executive
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Multi-purpose tray media types	Bond paper, Envelopes, Labels, Transparencies
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Display	LCD
Market positioning	Business
Display number of lines	5 lines
Display number of characters	22
Standard interfaces	Ethernet, Parallel, USB 2.0
Security algorithms	MD5, SSL/TLS
Supported network protocols (IPv4)	ARP, PARP, BOOTP, DHCP, APIPA (Auto IP), WINS/NetBIOS, DNS, mDNS, LLMNR, LPR/LPD, Port9100, IPP/IPPS, FTP Server, TELNET Server, HTTP/HTTPS Server, SSL/TLS, TFTP Client/Server, SMTP Client, APOP, POP/SMTP, SMTP AUTH, SNMPv1/v2c/v3, ICMP, LLTD, Web Services Print, IFS Client, SNTP, LDAP, POP3/SMTP, FTP Client
Supported network protocols (IPv6)	NDP, RA, DNS, mDNS, LLMNR, LPR/LPD, Port9100, IPP/IPPS, FTP Server, TELNET Server, HTTP/HTTPS Server, SSL/TLS, TFTP Client/Server, SMTP Client, APOP, POP/SMTP, SMTP AUTH, SNMPv1/v2c/v3, ICMPv6, LLTD, Web Services Print, CIFS Clien, SNTP, LDAP, POP3/SMTP, FTP Client
Internal memory	64 MB
Processor model	VR5500
Processor family	NEC
Processor frequency	300 MHz
Sound pressure level (copying)	56 dB
Sound pressure level (printing)	52.6 dB
AC input voltage	110 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	85 W
Power consumption (average operating)	1080 W
Operating temperature (T-T)	10 - 32.5 °C
Operating relative humidity (H-H)	20 - 80 %
Mac operating systems supported	Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2
Windows operating systems supported	Windows 2000 Professional, Windows XP Home, Windows XP Professional, Windows XP Professional x64

Weight and Dimensions

Weight	18450 g
