Troubleshooting
Problem Possible Cause Action To Take
POWER button was not been
pushed or been pushed too short.
Press the POWER button and hold more
than 4 seconds.
UPS not on, LCD not light
PCB failure Replace the PCB, call for service
Power cord loose Replace the power cord
AC fuse burn out Replace the AC fuse
Line voltage too high, too low or
black out
normal condition
UPS always at battery mode
PCB failure Replace the PCB, call for service
Buzzer continuous beeping Overload Remove the nonessential loads
UPS does not provide expected
run time, low battery warning is
sounded prematurely.
Battery is weak due to wear or
successive mains outages
Allow UPS to recharge battery for a
minimum of 8 hours. If up sounds low
battery warning prematurely, when retested,
battery should be replaced.
Specifications
Type CMP-UPS500 CMP-UPS650 CMP-UPS800 CMP-UPS1000 CMP-UPS1200
Capacity 500VA/300W 650VA/390W 800VA/480W 1000VA/600W 1200VA/720W
Voltage 165VAC-275VAC Input
Frequency 50Hz
Voltage 220V ± 10% Output
Frequency 50Hz ± 0.5
Type Sealed, maintenance-free lead acid
Capacity 1X12V 7Ah 1X12V 9Ah 2X12V 7Ah
Backup Time
(half load)
Over 8 Minutes
Battery
Typical
Recharge Time
8-hour
LCD indicators Status NORMAL, FAULT, BATTERY, CHARGE, OVERLOAD
Audible Alarm Battery Mode Beeps every four seconds. Beeps every second if approaches final discharge
Power
Maragement
Software
UPSilon2000 Option
Overload Automatic cut off output and beep last for 30 Seconds
Battery Low
Voltage
Automatic cut off output
Protection
Short Circuit Automatic cut off output and beep last for 30 Seconds
Temperature 0 ~ 40°C
Humidity 10%RH~90%RH
Operating
Environment
Audible Noise ≤ 45dB(A)
Size (mm) 330 × 85 × 155 300 × 120 × 195 Physical
Net Weight (Kg) 6.5Kg 13.2Kg
Performance
Uninterruptible Power
