Konig SAS-TRANS40 - Camera Channel Switch and Components; Channel Switch Operation; Camera Power Input and Connectors

ENGLISH
3
4. CHANNEL SWITCH
1. Remove the antenna
2. Remove the rain cover
3. Remove the lens cover by turning it
counter-clockwise.
4. Switch for
channel setting
Channel 4 Channel 3 Channel 2 Channel 1
(Make sure that both the camera and receiver are set to the same channel)
5. DC POWER INPUT (only use the supplied 9 V/400 mA, AC/DC adapter)
6. MOUNTING BRACKET
7. 5.8 GHz ANTENNA
8. ALUMINUM COVER (removable)
9. BUILT-IN MICROPHONE
