* Press [RELEASE CHANNELS] under MANUAL mode to get left menu.
* FFFFFFFF A -- Show 1-8 channel status
* FFFFFFFF B -- Show 9-16 channel status
* FFFFFFFFC -- Show 17-24 channel status
* O -- current channel under manual mode
F -- current channel under auto mode
* Press SA/SB/SC to select relative channel and move sliders of it to change status
10 LCD display
Display
Specific information
XXXXXX XXXX
Model and version number
S/N:0020-02-2727****
TEST OK
Series Number and Test condition
RUN Chase[??]
[01][00.0][00.0]
[??] -- Input chase / step number
[01] -- Step number of chase
1st [00.0] -- Chase running time
Last [00.0] -- Chase cross speed
RUN Chase[??]
CH[** [***]
[***] [***]
The upper line shows current running chase and
bottom line indicates current modified channel num
ber and channel data.
RUN SCENE
SELECT P1--P24
* Press P1 to P20 to select 20 steps of 1st chase
* Press P21-P24 to select 1st 4 steps of 2nd chase
EDIT Chase[??]
Step[01] [**]
Press [EDIT/RUN] and then corresponding indicate light ON
to enter EDIT situation.
[??] -- Edit chase number
STEP[01] -- Chase step number, modify it with
[**] -- current step is last step of edit chase. There will no
number if it has data already
[ -]or[+ ]
EDIT Chase[??]
CH[** [***]
or [***] [***]
The upper line shows current edit chase number ,
and the bottom line represents the modified channel
number and channel data.
EDIT Chase[??]
SPEE [***]
or CROS [***]
The upper line represents the chase number to be edited,
and bottom line indicates current modified chase running
speed or cross time
12345678
FFFFFFFF A
or FFFFFFFF B
or FFFFFFFF C
DMX 512 CONTROLLER SERIES
9/12
USER MANUAL
