DMX 512 CONTROLLER SERIES
3/12
3 Contents in the package
console 1PC
user's manual 1PC
Power adapter 1PC
l
l
l
Crocodile series
Crocodile series
4Signalcable
l
l
l
It use double-shield wire with the specified impedance of 120 ohms, and if
the cable exceeds 200 meters long or there are too many scanners a signal amplifier
should be added, and a terminal resistor should be added to the last scanner(120 ,1/4W).
he 1st pin of the signal cable is the grounding GND 2nd pin is negatives
and 3rd pin is positive signal; they should not be inversely connected and should not
be coldly welded.
The signal cable should not be shielded by single-terminal earthing.
The signal cable should not be wired together with strong electricity
Tl
