DMX 512 CONTROLLER SERIES
12 Running chases
1 Press[EDIT/RUN] until indicate LED OFF.
2 Press number keys P1-P24 to select chase number and run it; if that chase number has
not been edited, then the corresponding LED will not ON.
3 Move sliders of [SPEED] and [CROSS] chase running speed and cross time. If [SPEED] or
[CROSS] slivers is at bottom AUTO area, then the chase will run as preset speed and cross
time.
Press[+ ] to save current chase/step and enter next step editing. Press[ -],can
view last chase or repeat above 4,5,6 and 7 steps to modify it and press[+ ] again to save it).
Repeat steps 4 to 8 to edit other chases/chase steps.
Press [EDIT/RUN] until relative indicate light off to quit program status and run program.
Repeat steps 2 to 10, to edit other chases.
8
9
10
11
11 Edit scanner chase
1 Press [BLACK] to turn off correspondent LED indicate light.
2 Press [EDIT/RUN] to turn on relative LED indicate light, and enter the program state.
3 Press any one of the number keys P1-P24 one time, to select edit chase number [ ].
4 Then press numbers (P1-P20 , to select controlled scanner and correspondent LED ON. If
correspondent indicate LED not ON, it means that scanner not be selected and Step 5 will
no effect with it.
5 Move sliders of CH1-8 to change value or press [SB/SC] to change CH9-24 value.
and slide (CH9-CH24) to call out the corresponding scanner effect(Control joystick to
change value If X/Y channel be assigned to joystick).
6 Repeat steps 4, and 5 to program other scanners to get expect effect
7 Move sliders of [SPEED] and [CROSS] set chase running speed and cross time.
MANUAL [??]
FFFFFFFF A
or FFFFFFFF B
or FFFFFFFF C
Set X-Y
X[]Y[]
Press [EDIT] and [SET X/Y], select scanner by P1-P20 ( Set X/Y for all scanners
if not select scanner by P1-P20), press SA/SB/SC to select relative channel to
assign to joystick or press [DELETE] to delete previous assignment setting
* Press MANUAL during program running:
[??] -- Display current running Chase / Step
FFFFFFFF A -- Show 1-8 channel status
FFFFFFFF B -- Show 9-16 channel statu
FFFFFFFF C -- Show 17-24 channel statuss
O -- current channel under manual mode
F -- current channel under auto mode
* Select one scanner or several scanners via P1-P20
* Press SA/SB/SC to select relative channel and move sliders of it to change
status
10/12
