DMX 512 CONTROLLER SERIES
2/12
Thanks for using scanner console! The console has
internationally standard DMX512 signal output. Before operation,
please refer to the use's manual carefully.
crocodile series
1 parameters
Total number of channels
504 channels
Number of scanners
scanner
Max.number of channels for the
scanner
24 channels
24 chase
Maximal number of chase
steps(scene)
20 steps
Total number of chase
steps(scene)
480 steps
Scene pause time
0.1-25.5 second/step
Scene cross speed
0-25.5 seconds
Dimmer channel
channels
Display screen
DMX 512 outputs
interface
Memory capacity
Input voltage
AC100-240V 50/60Hz 9V/1000mA
Volume
Weight
485mmX250mmX91mm
5Kg
2.
The console must be connected to the safety earth line.
Never pulling out or inserting the communication cable with electricity.
Start order please turn on all the controlled scanner power supplies first,and then
turn on the controller power,otherwise the controller is easy to be destoryed.
prevent it from damp, water,dust,static, and maintain and clean it regularly.
Safety use cautions
l
l
l
l
Output signal specifications
DMX 512/1990 internationally standard
Number of chases(scenes)
LCD display,16*2 characters
3-Pin XLR input/output
512K high capacity memory card
USER MANUAL
