Duplex button area
Please refer to instruction details of the duplex key
8
Page turning 1
Page turning 2
Page turning 3
LED ON: Slider area CH1-8correspond to
LED ON: Slider area CH9-16correspond to
LED ON: Slider area correspond to CH17-24
9
10
11
Joystick (Fine Key)
12
Control X, Y of scanner or press it to fine adjust X,Y
SPEED CROSS
AUTO
SPEED slider Change chase running time during
program or running period
CROSS slider Adjust chase fade time during program
or running period
he upper
part is used to change time manually accord
situation.)
*
*
*AUTO:Setbothspeed&crossslidersatbottommeans
run program in original time setting. (T
13
LCD 16*2
Display relative data
14
CH1-16
(channel Data slider area)
Manual control selected lighting fixture DMX /dimmer
channel value to active relative function
15
DMX 512 CONTROLLER SERIES
7/12
6-7
P1-P24
Number key area
* Edit program state - Select chase number and controlled
scanner number. Press number key one time to select
edit chase number and then press number key again to
selectthenumberofscannerwanttobecontrolled.
* Running program - Select chase number expect to run.
Work with function key to select scanner number and set
all 20 steps of 1st chase and first 4 steps of 2nd chase as
24 separately steps.
USER MANUAL
