Part Number STH063 9/17 143
Number Component
1 Air Pump Harvest Assist
3 Bin Switch
5 Compressor
7 Compressor Overload
9 PTCR
11 Compressor Run Capacitor
14 Condenser Fan Motor
15 Condenser Fan Motor Run Capacitor
16 On/Off/Clean Switch
17 Contactor Coil
18 Contactor Contacts
19 Control Board
25 Fan Cycle Control
26 Harvest Float Switch
27 Water Level Float Switch
28 Fuse
31 High Pressure Cutout
41 See Control Board Schematic For Detail
42 Solenoid Valve - Harvest Left Hand
43 Solenoid Valve - Harvest Right Hand
54 Transformer
55 Water Dump Valve
56 Water Inlet Valve
58 Water Pump
Wire Colors
BLK Black
BLU Blue
BRN Brown
GRY Grey
ORG Orange
PRPL Purple
RED Red
WHT White
YEL Yellow
Refer to control board schematic for control board detail
To Next Page
