Part Number STH063 9/17 23
Calculating Allowable Lineset Distance
Line Set Length
The maximum length is 100’ (30.5 m).
Line Set Rise/Drop
The maximum rise is 35’ (10.7 m).
The maximum drop is 15’ (4.5 m).
MAXIMUM
DISTANCE
The maximum distance the Condenser
or Condensing Unit can be above the ice machine.
MAXIMUM
DISTANCE
The maximum distance the Condenser
or Condensing Unit can be below the ice machine.
