2.2.2 VESA Bracket Installation
Ν WARNING: Wall mounting screws require M4 screws , the length should not
exceed 8mm，avoid damage to the product due to excessive length.
VESA support
75×75mm
Assembled the
VESA screws
Ν
Ν
Wall Mount Notes
Please purchase the VESA bracket device separately.
For more information, please refer to the user guide provided with your VESA
bracket device.
Insert the base into the column according
to the direction shown in the figure;
Check whether the base and the column
are firmly connected, and place the
installed product on a stable platform
according to figure 1.5 - monitor
pick-and-place method.
05
