2. L->L , RETURN SW On

DSP So1L (0.031(=1/2*16)) ---> DSP Si1L (0.338713 +-30%)

INSERT(*1/2)+----->PHONEL

||CODEC(AK4522)|+--->PHONER

||+-------+-------+||

IN---+(-->)+--*16-->|AinL|AoutL|----+-|----->OUT-L

↑|AinR|AoutR|------+----->OUT-R

RETURNOPEN|||

+--|DoutL|DinL|<---+

+-|--|DoutR|DinR|<-+|

||+-------+-------+||

||||

||DSP(FXD03)||

||+-----------+||

|+-->|Si1LSo1L|-----|-+

+---->|Si1RSo1R|-----+

+-----------+

3. R->R , RETURN SW Off

DSP So1R (0.500(=1/2)) ---> DSP Si1R (0.338713 +-30%)

+----->PHONEL

CODEC(AK4522)|+--->PHONER

+-------+-------+||

|AinL|AoutL|----+-|----->OUT-L

IN------------------->|AinR|AoutR|------+----->OUT-R

|||
